Powerwinch 915 Heavy-Duty Trailer Winch With 1500-Lb Capacity And Gear Reduction

Description

12v Electric Trailer Winch
Model 915 12V power-in/power-out allows you to control your boat as it is lowered into the water. The 915 comes complete with a 10′ remote control cord and switch. It also features a pulley block for double-line applications, emergency hand crank and a 60 amp standard wiring harness.

• Max. boat length: 29′
• Max. boat weight: 9500 lbs
• Vertical lift capacity of 3200 lbs, double line capacity of 7500 lbs. (not to be used as a hoist)
• Power-in/power-out control
• Line speed 10 FPM
• 12 volt operating power
• 10′ remote control cord and switch
• 40′ x 7/32″ cable
• Manual hand crank
• Pulley block for double-line applications
• 60 amp standard wiring harness

Specifications:

• Pull Strength (lbs): 3200 lbs
• Manual/Electric: Electric
• Gear Ratio: 450:1
• Box Dimensions: 9″H x 11″W x 15″L WT: 38.9 lbs
• UPC: 810123840120
